MP13-10 Small CNC Milling Machine Tool Setter 10mm Diameter 1.0N Contact Force 0.001mm Z Axis Zero 2 Core Height Sensor

Name: MP1310 Small CNC Milling Machine Tool Setter 10mm Diameter 10N Contact Force 0001mm Z Axis Zero 2 Core Height Sensor
Brand: MAKINOPC
Price: 29 USD

Buy cheap MP13-10 Small CNC Milling Machine Tool Setter 10mm Diameter 1.0N Contact Force 0.001mm Z Axis Zero 2 Core Height Sensor product

Brand Name : MAKINOPC

Contact force : 1.0N (Mounting condition must be vertical)

Price : $29-35 / piece

Product Name : Small Type Automatic Tool Setter

Protection structure : IP68 depth waterproof

Diameter of counterface : 10mm

Place of Origin : Guangdong, China

video outgoing-inspection : Provided

warranty : 1 Year

Output Mode : NC normally closed type

machinery test report : Not Available

weight (kg) : 1.5

Machine Type : Milling Machine, Grinding Machine, turning machine

MOQ : 1 piece

Product Model : MP13-10

Repeatability : 0.0005mm (Condition: Operating speed 50-200mm/min)

Stroke : 5m

Contact life : 3 million times

Cable : 2m oil resistant (length can be customized), 2 cores

Contact Now

Products Description

Chinese Factory Original MP13-10 Small Tool Setter with Diameter 10mm Cutting Face Z Axis Zero Pre Setting CNC Machine Probe Pre-setters

This small tool setter MP13-10 is used for CNC engraving and milling machines, high-gloss machines, glass and jade machine tool measurement, wear and tear fracture detection; 0.001mm repeatability, improve machining accuracy, shorten the tool measurement time, improve the efficiency of machine tool operation.

Product Paramenters

Product Name	Small Type Automatic Tool Setter
Product Model	MP13-10
Diameter of counterface	10mm
Output Mode	NC normally closed type
Pre-stroke	No
Stroke	5m
Repeatability	0.0005mm (Condition: Operating speed 50-200mm/min)
Contact life	3 million times
Protection structure	IP68 depth waterproof
Contact force	1.0N(Mounting condition must be vertical)
Contact surface material	Super hard alloy
Surface treatment	Grinding 4S
Contact rating	DC24V-20mA(MAX)(Recommended value 10mA) Resistance Load
Contact voltage	DC24V 100mA resistive load
Cable	2m oil resistant (length can be customized), 2 cores
Net Weight	149. 3g
Gross Weight	180g

Details Images

MP13-10 Small CNC Milling Machine Tool Setter 10mm Diameter 1.0N Contact Force 0.001mm Z Axis Zero 2 Core Height Sensor

Product packaging

We usually use foam board with 3 cm thick to fill in all around the box inside to protect parts. We often use carton to pack the parts, but if it's too heavy, we'll use custom-wooden box to pack it. Package : carton or wooden box Lead time : 1-2 days All products can be shipped around the world via DHL, UPS, FedEx, TNT and more. The package is safe and green. If you have any special needs, please let me know.

Company Profile

Shenzhen Muye Precision Control Electromechanical Co., Ltd., established in 2014, is a service-oriented enterprise specializing in the R&D, design, and sales of CNC machine tool accessories. Our current product portfolio primarily includes: CNC machine tool probes, automatic tool setters, electronic handwheels, manual pulse generators, measuring styli, spindle encoders, band switches, sensors, and installation/commissioning solutions for automatic tool changers. Our factory is located in Songgang Town, Bao'an District, Shenzhen, covering an area exceeding 3,000 square meters. We employ 20 professional technicians, operate 15 testing instruments, and maintain two production lines, achieving a monthly production capacity of 100,000 units. Our products feature exclusive patented designs and proprietary brands, and have obtained multiple international quality certifications including CE, FCC, and RoHS. Our products are widely compatible with PLC control systems including Fanuc, , Mitsubishi, Fagor, Heidenhain, Baoyuan, New Generation, Hanac, GSK CNC (Guangzhou), Open Source CNC, KND, Norson, Delta, and more. They serve CNC machining centers, engraving machines, engraving/milling machines, drilling/reaming machines, EDM machines, milling machines, lathes, and other equipment. Guided by the business philosophy of “Customer First, Integrity-Based,” the company has established long-term partnerships with numerous enterprises. We warmly welcome professionals worldwide to visit and discuss business opportunities.

Our Advantages

1. We specialize in the field of CNC machine tool accessories and have more than ten years of industry experience. 2. We have our own brand called Makinopc and exclusive patent design and quality certification. 3. We provide you with friendly English user manual or operation video for free. 4. We have 24 hours technical support by email or phone. 5. Warranty: 1 year free warranty, 2-3 years warranty at cost, and always provide free technical support. 6. We have no MOQ limit and accept OEM/ODM bulk orders.
